Jumbo Frame Support
- Allows a much larger frame size of up to 2000 Bytes to be sent over a network
Plug and Play
- Supports Auto-Negotiation RJ45 ports (Auto MDI/ MDIX)
Store-and-Forward switching method
- Eliminates bad data packets from the network
Robust Design
- Sturdy and Strong plastic frame, can be placed on a desktop or any easily accessible location
Excellent Performance
- Supports Full/ Half duplex transfer mode for 10/100Mbps
|
Number of Ports
|
- 16 x 10/100Mbps Auto MDI/MDIX ,Auto Negotiation ports
|
|
Cable Type
|
- 10Base-T: UTP category 3, 4, 5 cable (maximum 100m)
- 100Base-Tx: UTP category 5, 5e cable (maximum 100m)
|
|
LED Indicator
|
- 10/100M: Link/Act(Green); Other: Power (Green)
|
|
Switching Capacity
|
|
|
MAC Address List
|
|
|
Frame Filtering & Forward Rate
|
|
|
Environment
|
- Operating Temperature: 0 °C ~ 40°C
- Storage Temperature: -40°C ~ 70°C
- Operating Humidity: 10%~90% non-condensing
- Storage Humidity: 5% ~ 90% RH, non-condensing
|
|
Dimensions
|
150 x 95 x 41.6mm (L x W x H)
|
|
Weight
|
293g
|
| |
|
|
)
